Mercury FourStroke 3.5

Specifications

  • Manufacturer: Mercury
  • Model: FourStroke 3.5
  • Type: 2.5 - 60
  • HP / kW: 3.5 / 2.6
  • Engine type: 1 cylinder
  • Displacement (CID/CC): 5.2 / 85
  • Full throttle RPM: 5000-6000
  • Fuel induction system: 2-valve pushrod (overhead valve)
  • Recommended fuel: 87 octane / up to 10% ethanol
  • Recommended oil: Mercury FourStroke Oil 10W-30
  • Engine protection operator warning system: Over-rev
  • Starting: Manual
  • Steering: Tiller with 360° turning
  • Shaft length: 15" / 381 mm, 20" / 508 mm
  • Gearcase ratio: 2.15:1
  • Dry weight *Lightest model available: 41 lbs / 18 kg
  • CARB star rating: 3
  • Bore and stroke: 2.16 x 1.42" / 55 x 36 mm
  • Ignition: CDI w/electronic spark advance
  • Fuel system: Carbureted
  • Cooling system: Water-cooled with thermostat
  • Gear shift: F-N
  • Gearcase options: Standard
  • Trim system: 4 position
  • Trim positions: 4
  • Exhaust system: Above prop
  • Shallow water trim range (degrees): 16
  • Integrated fuel tank (gal / L): 0.3 / 1.1
  • Color: Phantom Black
